power generation engines-380KW-YM6S9LF-DA
YTO DIESEL ENGINES FOR GENERATOR
| YM6S9LF-DA 380KW/1500RPM 390KW/1800RPM | |
| Model | YM6S9LF-DA |
| Type | Vertical,water cooling, four stroke |
| Combustion chamber type | Direct injector |
| Number of cylinders | 6 |
| Bore(mm) | 126 |
| Stoke(mm) | 130 |
| Compression ratio | 16.5:1 |
| Total displacement(L) | 11.54 |
| Firing order | 1-5-3-6-2-4 |
| Rated Power (KW)/Speed(RPM) | 410/1500 420/1800 |
| Min.specific fuel consumption at full load (g/kW.h) | 210 |
| Intake Type | Turbocharged with Aftercooler |
| Cooling method | water cooling |
| Starting method | Electric |
| flywheel size | SAE14 |
| Bell housing size | SAE1 |
| Net mass without radiator | 1050 |
| Overall dimensions (L*W*H) (mm) without radiator | 1547*950*1678 |
